晶体滤波器 HC-49U/HC-49T 类型

深圳市维创电子技术有限公司

www.WTT.CN

晶体滤波器 HC-49U/HC-49T 类型

发布时间: 2024-12-23 11:26

晶体滤波器 HC-49U/HC-49T 类型

商品信息

Part Number	Nominal Frequency MHz	Pass Band kHz/dB	Stop Band kHz/dB	Ripple dB	Insertion Loss dB	Terminal Impedance Ohm/pF	Operation Temperature ℃	Oscillation Mode	Pole
10M07A1	10.7	±3.75/3	±18/20	0.5	2.0	1800//5	-20 to +70	Fund	2
10M07A2	10.7	±3.75/3	±20/20	0.5	2.0	1800//5	-20 to +70	Fund	2
10M12A	10.7	±6.00/3	±20/18	0.5	2.0	3000//3	-20 to +70	Fund	2
10M15A	10.7	±7.50/3	±25/18	0.5	2.0	3000//2	-20 to +70	Fund	2
10M20A	10.7	±10.0/3	±35/18	0.5	2.0	2k-3k	-20 to +70	Fund	2
10M30A	10.7	±15.0/3	±50/18	0.5	2.0	5500//1	-20 to +70	Fund	2
10M07B1	10.7	±3.75/3	±14/40	1.0	2.5	1800//4	-20 to +70	Fund	4
10M07B2	10.7	±3.75/3	±15/40	1.0	2.5	1500//4	-20 to +70	Fund	4
10M12B	10.7	±6.00/3	±20/40	1.0	2.5	2800//1	-20 to +70	Fund	4
10M15B1	10.7	±7.50/3	±25/40	1.0	2.5	3000//1	-20 to +70	Fund	4
10M15B2	10.7	±7.50/3	±25/40	1.0	2.0	3000//2	-20 to +70	Fund	4
10M15B3	10.7	±7.50/3	±27/40	1.5	2.5	2k-3k	-20 to +70	Fund	4
10M20B	10.7	±10.0/3	±34/40	2.0	2.5	2k-3k	-20 to +70	Fund	4
10M30B	10.7	±15.0/3	±50/40	1.0	2.5	5500//1	-20 to +70	Fund	4
